1kg load pneumatic manipulator industrial robot mechanical arm automatic

Product Parameters: ModelHK5404Working radius540mmNumber of axis3 Axis/4 AxisinstallationFloorN.W.13kgPosition  repeatability ±0.05mmMax playload1kgPower Consume0.4KVAPower supplyInput:Single phase 110V-240V  50Hz         Output:DC 24V(400W)External communic

Featured Products

1kg Load Pneumatic Manipulator Industrial Robot Manipulator Arm for Automatic
Product Parameters:
ModelHK5404
Working radius540mm
Number of axis3 Axis/4 Axis
installationFloor
N.W.13kg
Position  repeatability ±0.05mm
Max playload1kg
Power Consume0.4KVA
Power supplyInput:Single phase 110V-240V  50Hz
Output:DC 24V(400W)
External communicationWIFI/Ethernet
ApplicationPicking, Loading, Casting, Polishing Etc
Safety standardISO 9001-2015
Control software Hulkbot Studio
Drive SystemSteper motor
Working condition-10°C~60°C
I/OInput 5/Output 5

Axis'Working Range:
Working envelopeJ1±160°
J2-42°~85°
J3-20°~100°
J4±165°

Max SpeedJ1360°/s
J2360°/s
J3360°/s
J4500°/s
